| Diameter (mm) | Mass Air (kg/m) | Mass Water (kg/m) | Breaking Force 1770 (kN) | Breaking Force 1960 (kN) | Breaking Load 1770 (Ton) | Breaking Load 1960 (Ton) |
|---|---|---|---|---|---|---|
| 26 | 2.97 | 2.52 | 568 | 613 | 57.9 | 62.5 |
| 26 | 3.11 | 2.64 | 595 | 642 | 60.7 | 65.4 |
| 28 | 3.61 | 3.07 | 690 | 745 | 70.3 | 75.9 |
| 30 | 3.76 | 3.19 | 719 | 776 | 73.3 | 79.1 |
| 30 | 4.23 | 3.6 | 792 | 855 | 80.7 | 87.2 |
| 30 | 4.64 | 3.94 | 887 | 958 | 90.4 | 97.7 |
| 32 | 4.71 | 4.08 | 901 | 973 | 91.8 | 99.2 |
| 34 | 5.32 | 4.52 | 1020 | 1100 | 104.0 | 112.0 |
| 35 | 5.61 | 4.77 | 1070 | 1160 | 109.0 | 118.0 |
| 38 | 5.96 | 5.02 | 1140 | 1220 | 116.0 | 124.0 |
| 40 | 6.64 | 5.65 | 1270 | 1360 | 129.0 | 139.0 |
| 41 | 7.36 | 6.25 | 1410 | 1500 | 144.0 | 153.0 |
| 41 | 7.84 | 6.66 | 1500 | 1600 | 153.0 | 163.0 |
| 44 | 8.11 | 6.9 | 1550 | 1660 | 158.0 | 169.0 |
| 44 | 8.91 | 7.57 | 1700 | 1820 | 173.0 | 186.0 |
| 46 | 9.09 | 7.73 | 1740 | 1860 | 177.0 | 190.0 |
| 48 | 9.73 | 8.27 | 1860 | 1990 | 190.0 | 203.0 |
| 50 | 10.8 | 9.2 | 2030 | 2160 | 207.0 | 220.0 |
| 50 | 11.5 | 9.78 | 2200 | 2330 | 224.0 | 238.0 |
| 52 | 12.4 | 10.4 | 2270 | 2430 | 231.0 | 248.0 |
| 52 | 12.7 | 10.8 | 2380 | 2510 | 243.0 | 256.0 |
| 54 | 13.7 | 11.6 | 2570 | 2740 | 262.0 | 276.0 |
| 56 | 14.7 | 12.5 | 2760 | 2950 | 281.0 | 296.0 |
| 58 | 15.8 | 13.4 | 2960 | 3180 | 302.0 | 319.0 |
| 60 | 16.7 | 14.2 | 3200 | 3360 | 326.0 | 341.0 |
| 60 | 17.1 | 14.5 | 3280 | 3540 | 334.0 | 361.0 |
| 62 | 18.1 | 15.4 | 3360 | 3630 | 343.0 | 370.0 |
| 64 | 19.3 | 16.4 | 3570 | 3840 | 364.0 | 392.0 |
| 66 | 20.5 | 17.4 | 3780 | 4060 | 386.0 | 414.0 |
| 68 | 21.6 | 18.3 | 3910 | 4200 | 399.0 | 415.0 |
| 70 | 22.5 | 19.2 | 4310 | 4460 | 439.0 | 455.0 |
| 72 | 23.8 | 20.3 | 4560 | 4700 | 465.0 | 479.0 |
| 73 | 24.5 | 20.9 | 4690 | 4800 | 478.0 | 489.0 |
| 76 | 26.6 | 22.6 | 4950 | 5070 | 505.0 | 517.0 |
| 77 | 26.7 | 22.7 | 5080 | 5220 | 518.0 | 533.0 |
| 80 | 29.4 | 25.0 | 5630 | 5700 | 574.0 | 581.0 |
| 82 | 31.3 | 26.6 | 5520 | 5930 | 563.0 | 604.0 |
| 84 | 32.5 | 27.6 | 5720 | 6140 | 583.0 | 626.0 |
| 86 | 34.0 | 28.9 | 5990 | 6360 | 611.0 | 648.0 |
| 88 | 35.6 | 30.3 | 6270 | 6580 | 639.0 | 671.0 |
| 90 | 37.3 | 31.7 | 6560 | 6890 | 669.0 | 702.0 |
| 92 | 39.0 | 33.1 | 6870 | 7210 | 700.0 | 735.0 |
| 94 | 40.6 | 34.5 | 7160 | 7420 | 730.0 | 756.0 |
| 96 | 41.7 | 35.4 | 7350 | 7620 | 749.0 | 777.0 |
| 98 | 43.6 | 37.0 | 7650 | 7900 | 780.0 | 806.0 |
| 100 | 44.6 | 37.9 | 7850 | 8040 | 800.0 | 820.0 |
| 102 | 47.9 | 40.2 | 8340 | 8530 | 859.0 | 870.0 |
| 104 | 49.8 | 42.3 | 8670 | 8870 | 893.0 | 904.0 |
| 106 | 51.7 | 43.9 | 8930 | 9040 | 910.0 | 922.0 |
| 108 | 53.7 | 46.5 | 9340 | 9540 | 954.0 | 973.0 |
| 109 | 54.7 | 46.5 | 9620 | 9820 | 980.0 | 999.0 |
| 112 | 57.7 | 49.0 | 10000 | 10200 | 1020.0 | 1040.0 |
Durable and reliable
All our Usha Martin steel wire ropes are 100% certified and manufactured to the highest quality standards. That’s why you always receive a 1-year warranty as standard on our ropes. Due to our high quality standards, we are also officially approved by ABS, API, DNV, Lloyd’s, BV and NKK.
About Usha Martin
Usha Martin Europe is part of the Usha Martin Group, one of the world’s largest steel wire rope manufacturers. We are based in Dordrecht and serve as the sales and distribution center for Europe.
Need help?
Call us: +31 180 74 50 99
Email us: info@ushamartineurope.com
Oceanmax steel wire ropes for oil and gas applications
Oceanmax is the new wire rope label from Brunton Shaw, specially developed for the most demanding applications in the oil and gas industry. With decades of experience in manufacturing specialty ropes, Brunton Shaw takes a major step forward with this next generation of steel wire ropes. These ropes are designed and manufactured according to the strictest technical specifications, meeting the tough demands of today’s environment.
Our specialized team works closely with customers to provide innovative solutions for the most complex challenges, such as heavy lifting operations in offshore environments. Thanks to ongoing investments in new technology, modern production facilities, and product development, Oceanmax meets the highest industry standards.
As part of the globally renowned Usha Martin Group, Brunton Shaw benefits from a fully integrated supply chain – from its own raw material sourcing to advanced manufacturing plants in India, the United Kingdom, Thailand, and Dubai. With service centers around the world, Usha Martin ensures reliable global delivery and support.
Oceanmax stands for strength and innovation, as well as global quality and consistency. Wherever you are in the world – Usha Martin remains committed to living up to its reputation for top quality.
Request a quick quote
